OEM VACUUM PUMPS AND PARTS

Water Ring Vacuum Pump:

Comparing with the SK, 2SK, SZ series water ring vacuum pumps, the 2BE series products are the ideal replacements pump due to its high vacuum, low power consumption, and steady running reliability.
By way of changing the structural material, it is also available in aspirating corrosive gas or with the corrosive liquid as the operating liquid.
Due to our high quality and competitive price , our pump are widely used for original Siemens and Nash pump replacement in Mining industry, Electric power industry,petro chemical industry, pulp and paper industry,pharmaceutical industry,environment industry,food and beverage industry,Marine Industry and other general industry price
Due to its competitive price and higher performance, our pump is best choice for Siemens and some Italy pump replacement.

The main characteristics of 2BE1 series products:
2BE water ring vacuum pump is a high efficiency and energy-saving product developed by our factory on the basis of many years of scientific research and production experience, combined with the advanced technology of imported products. It is usually used to pump gas without solid particles, insoluble in water and corrosive, so as to form vacuum and pressure in closed container. By changing the structure material, it can also be used to suck corrosive gas or use corrosive liquid as working fluid. It is widely used in papermaking, chemical, petrochemical, light industry, pharmaceutical, food, metallurgy, building materials, stone tools, coal washing, mineral processing, chemical fertilizer and other industries.
Because in the working process, the pump compresses the gas in an isothermal state, so it can pump flammable and explosive gas. By changing the structural materials, it can also pump corrosive gas and use corrosive liquid as working fluid.
2BE water ring vacuum pump adopts single stage and single action structure, which has the advantages of simple structure, convenient maintenance, reliable operation, high efficiency and energy saving. Compared with SK, 2SK and SZ series water ring vacuum pumps which are widely used in China, they have obvious advantages of high vacuum degree and low power consumption. They are ideal substitutes for SK water ring vacuum pumps, 2SK water ring vacuum pumps and SZ series water ring vacuum pumps. It can be used as the front stage pump and roots vacuum pump to form roots water ring vacuum unit, and two 2be water ring pumps plus steam water separator, vacuum tank, heat exchanger, etc. can form a vacuum negative pressure station.Mechanical seals (not compulsory) use best materials to prevent leakage when the pump works for quite long time.

2, Product features
1. The optimized hydraulic design of flow passage components greatly improves the operation efficiency and remarkable energy-saving effect.
2. With lower impeller linear speed, the operation of the pump is more stable and reliable, and the noise is lower.
3. The exhaust port equipped with flexible valve plate can automatically adjust the exhaust angle and effectively prevent over compression in the exhaust process; The closed circulation of working fluid is adopted to greatly reduce the loss of water.
4. Equipped with automatic drain valve to control the starting liquid level of the pump to avoid overload starting.
5. When the closed circulation of working fluid is adopted, the loss of water can be greatly reduced. Through the self-priming capacity of the vacuum pump, the cooled working fluid is introduced into the pump without additional pressurization device.
6. When the pump body is equipped with diaphragm, a vacuum pump can pump different vacuum at the same time.
7. The pump body and side cover are connected by flange, which ensures the overall rigidity and anti vibration ability of large-scale water ring vacuum pump. When the maintenance space is small, horizontal assembly and disassembly can be implemented.
8. The packing gland is a semi split structure, which can be removed as a whole and the packing can be replaced.
9. The impeller reinforcing ring adopts inward moving design to prevent the retention of impurities and reduce the impact of water scaling on the pump.
10. When the overflow parts are made of stainless steel of different grades, they can meet different anti-corrosion requirements.
11. When the flow passage parts are sprayed with ceramic polymer material SEBF, while meeting the very stringent anti-corrosion requirements, its smooth surface can effectively reduce the precipitation of ash and slow down the scaling process.
12. The connection performance is good. When connecting with our 2BE1 series vacuum pump, there is no need to change the connecting pipeline, which greatly reduces the transformation cost.
13. Some parts can be exchanged with 2BE1 series vacuum pumps to reduce the cost of spare parts.
